Concrete Wet Mix Plant

Get a Price/Quote

Concrete Wet Mix Plant Specification

Product Type
Concrete Wet Mix Plant

General Use
Road Construction, Infrastructure Projects, Civil Engineering Works

Material
Mild Steel Structure with Heavy Duty Components

Type
Automatic Wet Mix Macadam Plant

Weight (kg)
18500

Computerized
Yes

Automatic
Fully Automatic

Control System
PLC based Control Panel

Power Source
Electric

Power Consumption
90 kW

Storage Capacity
40 - 200 TPH (varies by model)

Hopper Capacity
4 x 10 m3 (Standard)

Hopper Quantity
4

Conveyor Capacity
Variable Based on Plant Size (Typically 40-200 TPH)

Mixing Drum Speed
16-20 RPM

Discharging Height
3.8 m

Voltage
380/415 V

Dimension (L*W*H)
Variable (Approx. 13500 x 3200 x 4200 mm for standard)

Feature
Modular Structure, Easy Maintenance, Powerful Mixing, Highly Efficient

Color
Blue/Yellow (Customizable)

Control Cabin
Fully Enclosed with Operator Panel

Belt Width
600 mm (conveyor)

Operating Temperature
Up to 95C

Feeder Type
Synchronized Four-Bin Feeder with Individual Gates

Filler Feeding System
Screw Conveyor with Hopper

Water Tank Capacity
15000 Liters

Mixing Type
Twin Shaft Forced Mixer

Noise Level
< 85 dB (A) at Control Cabin

Aggregate Weighing System
Load Cell Based Precision Weighing

Aggregate Size
Up to 60 mm

Bitumen Addition
Optional Spray Nozzle System

Mobility
Stationary with Optional Semi-Mobile Skid

About Concrete Wet Mix Plant

Discover the superb Concrete Wet Mix Plant, a masterpiece of engineering crafted for efficiency, reliability, and cost-effectiveness. Take advantage of our current discount offer to acquire this noble solution for complex road construction, civil engineering works, and infrastructure projects. Featuring a synchronized four-bin feeder with individual gates, a powerful twin shaft forced mixer, and a precision load cell weighing system, it delivers consistent, high-quality output. The fully automatic PLC-based controls ensure seamless operation, while the modular design promises easy maintenance and adaptability. Don't miss this limited-time offer for enhanced productivity!

Versatile Application and Trusted Users

Concrete Wet Mix Plant serves as a robust solution for contractors, government agencies, and private companies engaged in road construction and heavy infrastructure projects. It is suitable for application media like aggregate blends, water, and bitumen, applied specifically in highways, bridges, airports, and civil engineering works. Used by site engineers, dealers, and service providers across India, this plant is trusted for its ability to handle demanding operational requirements seamlessly.

Sample Policy and Export Opportunities

We offer a transparent sample policy with sample units available upon request at a special sale price, ensuring clients experience premium quality. Contact us to learn more about exclusive limited-time offers and bulk discounts. Our main export markets include South Asia, Africa, and the Middle East, making us a preferred supplier globally. Experience the reliability and innovation of our wet mix plant-backed by expert service and support from our dedicated dealer network.

FAQ's of Concrete Wet Mix Plant:

Q: How does the load cell based aggregate weighing system enhance precision in the mixing process?

A: The load cell based aggregate weighing system accurately measures each component, ensuring consistent mixture quality batch after batch. This precision reduces material wastage and optimizes productivity during large-scale infrastructure projects.

Q: What is the maximum aggregate size that can be handled by the Concrete Wet Mix Plant?

A: The plant efficiently manages aggregate sizes of up to 60 mm, making it suitable for a wide range of road construction and civil engineering applications.

Q: Where can the Concrete Wet Mix Plant be installed for optimal use?

A: It is ideal for stationary installation at major project sites, with an optional semi-mobile skid available for enhanced flexibility across various locations and project types.

Q: When is bitumen addition required, and how is it incorporated in the system?

A: Bitumen addition is optional and is smoothly integrated using a spray nozzle system, which is particularly beneficial for applications requiring superior binding and surface finish in roadworks.

Q: What are the main benefits of the plant's modular structure and computerized control system?

A: The modular structure facilitates quick assembly, easy maintenance, and adaptability to different site layouts, while the computerized PLC control panel enables accurate operation, minimal downtime, and hands-on monitoring.
